XDA-1002

OMNITRONIC XDA‑1002 – Class‑D Stereo PA Amplifier, 2×510 W (4 Ω)

SKU: 10451635

Product Description

The OMNITRONIC XDA‑1002 is a compact Class‑D stereo PA amplifier designed for professional sound reinforcement, fixed installations and mobile DJ applications. Its integrated switch‑mode power supply ensures low weight and a slim 1U rack profile, making it ideal for portable setups and tight rack spaces.

The amplifier delivers 2 × 510 W RMS at 4 Ω, 2 × 300 W RMS at 8 Ω, or 1000 W RMS bridged at 8 Ω, providing strong output performance for clubs, dance studios, restaurants, gyms and rental systems. Balanced XLR inputs with feed‑through outputs, lockable speaker connectors and dual cooling fans ensure reliable operation in demanding environments. Protection circuits cover short‑circuit, overheating, DC voltage, soft‑start and power transients.

Key Features

• Class‑D stereo PA amplifier with SMPS

• 2 operating modes: Stereo or Bridged

• 2 × 510 W RMS (4 Ω), 2 × 300 W RMS (8 Ω), 1000 W RMS bridged (8 Ω)

• Balanced XLR inputs + XLR link outputs

• Lockable speaker outputs

• Dual cooling fans

• 1U 19" rackmount design

• Protection circuits: short‑circuit, overheat, DC, soft‑start, limit

• Ideal for clubs, studios, gyms, bars, hotels, mobile DJs and rental systems

Specifications

Electrical

Power supply: 230 V AC, 50 Hz Power consumption (1/8 power): 210 W Circuitry: Class‑D Input sensitivity: 1.25 V S/N ratio: > 100 dB THD: < 0.02% at 1 kHz

Output Power

Stereo 4 Ω: 2 × 510 W RMS Stereo 8 Ω: 2 × 300 W RMS Bridged 8 Ω: 1000 W RMS

Inputs & Outputs

Inputs: 2 × XLR (balanced) Link outputs: 2 × XLR Speaker outputs: 2 × lockable speaker sockets Input impedance: 20 kΩ balanced, 10 kΩ unbalanced

Controls & Indicators

Controls: power switch, level controls (per channel), mode switch (stereo/bridged), ground‑lift Status LEDs: Power, Signal, Protect, Limit

Cooling

Cooling: 2 × cooling fans

Physical

Rack format: 19" / 1U Mounting depth: 23.3 cm Dimensions (W × D × H): 48.3 × 24 × 4.45 cm Weight: 4.03 kg Housing color: Black

Packaging

EAN: 4026397580143 Shipping weight: 4.65 kg Package size: 54 × 36 × 8 cm

Identifiers

• SKU: 10451635

• HS Code: 8518.50.00
