PT-2H

Kramer PT-2H | HDMI Equalizer

Max. Data Rate — 4.95Gbps (1.65Gbps per graphic channel)
Range — Up to 38m (120ft)

The PT−2H is an equalizer for HDMI signals. The unit removes the digital noise (sparkles) in a video image that results from using a long HDMI cable.
 Resolution — Up to 1080p.
 HDTV Compatible.
 HDCP Compliant.
 Range — 38m (120ft).
 Powered from HDMI Source.

INPUT
 1 HDMI/DVI–TMDS on a type A 19–pin HDMI connector
OUTPUT
 1 HDMI, HDCP1.0/1.1 on a type A 19–pin HDMI connector
MAX. DATA RATE
 4.95Gbps (1.65Gbps per graphic channel)
HDMI COMPLIANCE
 HDMI
RESOLUTION
 All resolutions from VGA up to UXGA
DTV/HDTV VIDEO FORMAT
 480i, 576i, 480p, 576p, 720p, 1080i, and 1080p
MAX. RANGE
 1920 x 1200, 1080p — 38m (120ft): 23m from HDMI source to PT–2H, 15m* from PT–2H to HDMI acceptor. *For older models, 7m from PT–2H to HDMI acceptor (check with your local Kramer office)
Product Dimensions
 6.22cm x 5.18cm x 2.44cm (2.45" x 2.04" x 0.96" ) W, D, H
Shipping Dimensions
 9.50cm x 6.80cm x 4.20cm (3.74" x 2.68" x 1.65" ) W, D, H
Shipping Weight
 0.1kg (0.1lbs) approx.
