EM-760

OMNITRONIC EM-760 Entertainment Mixer

OMNITRONIC Entertainment Mixer Series
The modern entertainment industry, especially hotels, bars or theme parks, requires very high standards in quality and features for sound devices.
The OMNITRONIC EM-series is especially designed for this industry and offers the highest flexibility and quality in very small mixer casings.
The EM-series offers a variety of connection possibilities and also convinces by an ergonomic design and easy use.
The special housing design and the state-of-the-art construction are further reasons which make the EM-series the first choice for installers.

Multifunctional 6+1-channel installation mixer

• 6 input channels with gain control, 3-way equalizer and super smooth dual-rail channel faders
• 1 separate microphone channel with level control, 2-way equalizer and talkover button
• Pre-fader listening (CUE) to the stereo input channels via adjustable headphone output
• Color illuminated rotary controls and rubber buttons
• 2 adjustable master outputs with 10-digit stereo LED level meter
• 1 adjustable booth output with mono/stereo selector switch
• 2 record outputs, independent of the master channels
• Inputs: 9 x line (stereo RCA), 3 x line/phono (stereo RCA), switchable; 6 x microphone (6.3 mm jack), 1 x microphone (XLR/6.3 mm jack) and headphones (6.3 mm jack)
• Outputs: 2 x master (optionally 3-pin XLR or stereo RCA), 1 x booth (stereo RCA) and 2 x record (stereo RCA)
• Operation via supplied power unit
• Rack installation, 3 U
• Ideal for restaurants, bars, theme parks, hotels and all applications where microphones need to be mixed with music (e.g. karaoke)
• (19") 48.3 cm rack installation
