AVR147

AVR 147 5.1-Channel Audio/Video Receiver

Audio Section:

• 40 Watts x 5, five channels driven at full power at 8 ohms, 20Hz – 20kHz, <0.07% THD, (surround modes); 200 watts total

• 50 Watts x 2, two channels driven at full power at 8 ohms,

20Hz – 20kHz, <0.07% THD, (surround off mode); 100 watts total

• High current capability, ultrawide bandwidth amplifier design with low negative feedback

• All-discrete amplifier circuitry

• Dual independent power supplies, for front and surround channels

• Triple crossover bass management

• 24-Bit, twin-core Cirrus Logic® CS 49510 DSP processor with

32-bit post processor

• 192kHz/24-bit D/A conversion

• Sampling upconversion to 96kHz

Surround Modes

• Dolby® Digital

• Dolby Pro Logic® II (Movie, Music and Game)

• Dolby Virtual Speaker Version 2 (Reference 2- or 3-speaker; Wide 2-, 3-, 4- or 5-speaker)

• Dolby Headphone Version 2

• DTS® (5.1; DTS Stereo)

• DTS 96/24™ (DTS Stereo)

• DTS Neo:6® (Cinema 3- or 5-channel; Music 5-channel)

• Logic 7® (Cinema, Music and Enhance)

• Hall 1 and Hall 2

• Theater

• 5-Channel Stereo

• Surround Off (DSP or Analog Bypass)

FM Tuner Section:

Frequency Range 87.5–108.0MHz
Usable Sensitivity IHF 1.3µV/13.2dBf

Video Section:

2x HDMI in

1x HDMI out

General:

Weight 9.7kg

Dimensions WxHxD 440x165x382mm
