KAPPA 10.3T
Infinity KAPPA 10.3T One pair
The Infinity Kappa 10.3t is a high-performance 1-inch car audio tweeter featuring a Ceramic Metal Matrix Diaphragm (C.M.M.D.) dome. It is designed to deliver detailed, accurate high-frequency response with significantly reduced distortion compared to traditional metal domes.
Detailed Technical Specifications
- Tweeter Size: 1" (25mm) Ceramic Metal Matrix Diaphragm (C.M.M.D.) dome.
- Impedance: 4 Ohms.
-
Power Handling:
- RMS: 50 Watts.
- Peak: 150 Watts.
- Sensitivity (2.83V @ 1m): 90 dB.
- Frequency Response: 3.5 kHz – 21 kHz.
- Crossover: Includes a 3,500 Hz passive in-line crossover with I-mount capabilities.
Installation Dimensions
- Mounting Depth: 1-3/16" (31mm).
- Cut-out Diameter: 1-7/8" (47mm).
- Mounting System: Utilizes the I-Mount™ system, which allows for multiple mounting configurations including flush, surface, or angled installation.
